Deep Packet Inspection and Packet Manipulation

"A postal sorting facility usually just reads the address on the envelope and routes it accordingly -- it never opens the letter inside. Deep packet inspection is what happens when the sorting facility starts opening every envelope, reading the actual letter, and deciding what to do based on the content, not just the address. It can be used to catch a real threat hidden inside, or it can be an invasive overreach, depending entirely on who is doing it and why."

Every network tool you have built so far in this book -- TCP servers, proxies, HTTP clients -- has operated at the level the protocol intends: read the headers you are supposed to read, act on the payload your own application produced or expects. Deep packet inspection (DPI) is different in kind: it means examining packets your program did not originate and was not necessarily the intended final recipient of, looking past the headers that a router would normally use for forwarding, and into the payload itself, often reconstructing entire application-layer conversations from raw frames.

Why DPI Exists

Firewalls that only look at IP addresses and port numbers cannot tell the difference between legitimate HTTPS traffic and a tunnel smuggling something else over port 443. Intrusion detection systems need to match traffic content against signatures of known attacks, not just source and destination. Network operators doing traffic shaping need to identify what kind of traffic is congesting a link, not just how much of it there is. All three needs come back to the same requirement: look inside the packet, past the addressing information, at the actual bytes being carried.

The Go Tool for This: gopacket

The standard library's net package deliberately operates above this level -- it gives you a TCP stream or a UDP datagram's payload, not raw frames off the wire. Capturing and dissecting raw packets is the job of gopacket, Google's Go bindings around libpcap (the same capture engine behind Wireshark and tcpdump), paired with gopacket/layers, which understands the byte layout of dozens of protocols so you do not have to hand-decode Ethernet or IP headers yourself.

Go Implementation: Capturing and Inspecting Live Traffic

package main

import (
	"fmt"
	"log"

	"github.com/google/gopacket"
	"github.com/google/gopacket/layers"
	"github.com/google/gopacket/pcap"
)

func main() {
	const device = "eth0"
	const snapshotLen int32 = 1600
	const promiscuous = false

	handle, err := pcap.OpenLive(
		device, snapshotLen, promiscuous, pcap.BlockForever,
	)
	if err != nil {
		log.Fatal(err)
	}
	defer handle.Close()

	// A BPF filter narrows capture to traffic we actually care about,
	// pushing the filtering into the kernel instead of userspace.
	if err := handle.SetBPFFilter("tcp port 80"); err != nil {
		log.Fatal(err)
	}

	packetSource := gopacket.NewPacketSource(handle, handle.LinkType())
	for packet := range packetSource.Packets() {
		inspect(packet)
	}
}

func inspect(packet gopacket.Packet) {
	ipLayer := packet.Layer(layers.LayerTypeIPv4)
	tcpLayer := packet.Layer(layers.LayerTypeTCP)
	if ipLayer == nil || tcpLayer == nil {
		return
	}

	ip, _ := ipLayer.(*layers.IPv4)
	tcp, _ := tcpLayer.(*layers.TCP)

	fmt.Printf("%s:%d -> %s:%d [seq=%d]\n",
		ip.SrcIP, tcp.SrcPort, ip.DstIP, tcp.DstPort, tcp.Seq)

	appLayer := packet.ApplicationLayer()
	if appLayer != nil {
		payload := appLayer.Payload()
		fmt.Printf("  payload (%d bytes): %q\n",
			len(payload), truncate(payload, 80))
	}
}

func truncate(b []byte, n int) []byte {
	if len(b) > n {
		return b[:n]
	}
	return b
}

This is the essence of DPI: packet.Layer(layers.LayerTypeTCP) gets you the header a router would normally stop at, but packet.ApplicationLayer().Payload() reaches past it into whatever bytes the application actually sent -- an HTTP request line, a chunk of a file transfer, anything. The BPF filter (SetBPFFilter) matters for more than convenience: it runs in the kernel before packets even reach your Go process, so you are not paying userspace CPU cost to inspect and discard traffic you never wanted in the first place.

Reassembling a Conversation

A single packet is rarely the unit you actually want to inspect -- an HTTP request is usually split across several TCP segments. gopacket's tcpassembly (or the newer reassembly) subpackage reconstructs ordered, gap-free byte streams from a sequence of captured segments, handling retransmissions and out-of-order delivery the same way the kernel's own TCP stack would, so your inspection code can work with a coherent stream instead of raw, possibly-reordered fragments.

Packet Manipulation: The Other Direction

Everything above reads packets off the wire. gopacket also supports building and sending them, which is how you would implement a custom traffic generator, a protocol fuzzer, or a tool that needs to craft packets a normal net.Dial call could never produce (a raw ICMP echo, a TCP SYN with unusual flags for a scanning tool, and so on):

buf := gopacket.NewSerializeBuffer()
opts := gopacket.SerializeOptions{FixLengths: true, ComputeChecksums: true}

eth := &layers.Ethernet{ /* ... */ }
ipLayer := &layers.IPv4{Version: 4, Protocol: layers.IPProtocolTCP /* ... */}
tcpLayer := &layers.TCP{SrcPort: 12345, DstPort: 80 /* ... */}
tcpLayer.SetNetworkLayerForChecksum(ipLayer)

if err := gopacket.SerializeLayers(buf, opts, eth, ipLayer, tcpLayer); err != nil {
	log.Fatal(err)
}

if err := handle.WritePacketData(buf.Bytes()); err != nil {
	log.Fatal(err)
}

SerializeLayers writes each layer's header in order into the buffer, and FixLengths/ComputeChecksums fill in the length and checksum fields that would otherwise be tedious and error-prone to compute by hand -- exactly the kind of low-level correctness that makes hand-rolled packet crafting risky without a library like this one.

Where This Belongs in a Real System

DPI-style inspection is the mechanism behind intrusion detection systems (matching payloads against known attack signatures), application-aware load balancers (routing based on the actual protocol inside a TLS-terminated stream), and network troubleshooting tools that need to see what a tcpdump capture file actually contains, programmatically, instead of eyeballing it. Used within its legal and ethical bounds, it is one of the few tools that lets you verify what is really happening on the wire, rather than trusting what a protocol's headers claim.

Frequently Asked Questions

Why does net.Dial never see this kind of raw traffic on its own? Because the standard library is deliberately built to keep you above the fray -- it hands you an already-reassembled TCP stream or a UDP datagram's payload, precisely so you never have to think about Ethernet frames, IP headers, or checksums to write an ordinary client or server. gopacket exists as a separate, opt-in layer specifically because most Go network code should never need raw sockets at all; DPI is the exception, not the rule.

Do I need root or Administrator just to read traffic my own program sent? Yes, and that is by design, not an oversight. Reading packets off an interface means reading traffic that was not necessarily addressed to your process, so every major OS gates that behind CAP_NET_RAW/root on Linux, Administrator plus Npcap on Windows, and root on macOS. If pcap.OpenLive fails with a permissions error, that is the platform doing exactly what it is supposed to do.

What happens if I skip the BPF filter and just inspect everything in packetSource.Packets()? It will still work, but you will burn CPU cycles copying every single frame on the wire into your Go process's userspace just to throw most of them away. SetBPFFilter("tcp port 80") pushes that discarding decision down into the kernel, before the packet ever reaches your code -- on a busy interface that difference is the gap between a tool that scales and one that falls over.

My inspection code sees an HTTP request cut in half across two calls to inspect -- is that a bug? No, that is TCP working as intended: segments can arrive split at arbitrary byte boundaries, and a single captured packet is not the same thing as a single application-layer message. That is exactly the problem gopacket's tcpassembly/reassembly subpackage solves, reconstructing an ordered, gap-free byte stream out of individually-captured segments the same way the kernel's own TCP stack would.

Is crafting my own packets with SerializeLayers the same skill as the custom protocols in the next chapter? Related, but not the same layer of the stack. Here you are hand-assembling Ethernet, IP, and TCP headers below the transport your OS would normally manage for you -- useful for scanners, fuzzers, or generators that need frames a plain net.Dial could never produce. The next chapter's custom protocol design work happens above a transport that already exists, defining your own message format on top of a TCP or UDP connection you did not have to construct byte by byte.

Key Takeaways

• Deep packet inspection means looking past the headers a router would normally stop at, into the actual application-layer payload -- powerful, and a genuine legal and ethical boundary.
• gopacket (Google's Go bindings around libpcap) is the standard tool for capturing and dissecting raw packets; the standard library's net package deliberately stays above this level.
• A BPF filter pushes discarding decisions into the kernel before packets reach your Go process, which matters enormously on a busy interface.
• A single captured packet is not the same as a single application message; tcpassembly/reassembly reconstructs ordered, gap-free streams from segments.
• Raw packet capture and injection require elevated privileges on every platform, by design -- reading traffic not addressed to your process is a restricted capability.
