APIs for Advanced Observability: Distributed Tracing

The previous chapter instrumented a single service well: structured logs, metrics, health checks. But a request to a modern API rarely stays inside one service — it hits a gateway, calls three internal services, one of which queries a database and another of which calls a third-party API. When that request is slow, "check the logs" means checking logs in four or five different places, with no obvious way to tell which log lines even belong to the same request. Distributed tracing solves exactly this problem, and this chapter builds it with OpenTelemetry, the vendor-neutral standard that has become the default choice for Go services.

What a trace actually is

A trace is a tree of spans — each span representing one unit of work (an HTTP handler, a database query, an outbound call) with a start time, a duration, and a parent-child relationship to other spans. All spans belonging to one logical request share a single trace ID, which is how a tracing backend (Jaeger, Tempo, or a vendor's hosted equivalent) reconstructs the full picture: this request touched the gateway, then the orders service, then the database, in this order, taking this long at each step.

Setting up the OpenTelemetry SDK

go.opentelemetry.io/otel is the vendor-neutral API; a separate exporter package ships the collected spans to your tracing backend over OTLP (OpenTelemetry Protocol):

package main

import (
	"context"

	"go.opentelemetry.io/otel"
	"go.opentelemetry.io/otel/exporters/otlp/otlptrace/otlptracehttp"
	"go.opentelemetry.io/otel/propagation"
	"go.opentelemetry.io/otel/sdk/resource"
	sdktrace "go.opentelemetry.io/otel/sdk/trace"
	semconv "go.opentelemetry.io/otel/semconv/v1.26.0"
)

func initTracing(
	ctx context.Context,
	collectorEndpoint string,
) (func(context.Context) error, error) {
	exporter, err := otlptracehttp.New(ctx,
		otlptracehttp.WithEndpoint(collectorEndpoint))
	if err != nil {
		return nil, err
	}

	res, err := resource.New(ctx, resource.WithAttributes(
		semconv.ServiceName("orders-api"),
	))
	if err != nil {
		return nil, err
	}

	tp := sdktrace.NewTracerProvider(
		sdktrace.WithBatcher(exporter),
		sdktrace.WithResource(res),
	)
	otel.SetTracerProvider(tp)
	otel.SetTextMapPropagator(propagation.TraceContext{})

	return tp.Shutdown, nil
}

otel.SetTextMapPropagator(propagation.TraceContext{}) is easy to skip and is the single most important line for distributed tracing specifically — it configures how trace context gets encoded into outgoing HTTP headers and decoded from incoming ones, using the W3C traceparent header standard, which is what lets a trace ID survive a hop from one service to the next.

Instrumenting HTTP servers and clients

go.opentelemetry.io/contrib/instrumentation/net/http/otelhttp wraps both sides of an HTTP call so that spans are created and propagated automatically, without hand-writing span creation into every handler:

import "go.opentelemetry.io/contrib/instrumentation/net/http/otelhttp"

func main() {
	mux := http.NewServeMux()
	mux.HandleFunc("/orders", ordersHandler)

	wrapped := otelhttp.NewHandler(mux, "orders-api")
	http.ListenAndServe(":8080", wrapped)
}

var tracedClient = &http.Client{
	Transport: otelhttp.NewTransport(http.DefaultTransport),
}

func callInventoryService(ctx context.Context, productID string) error {
	req, _ := http.NewRequestWithContext(ctx, http.MethodGet,
		"http://inventory-service/check/"+productID, nil)
	// propagates the trace context automatically
	resp, err := tracedClient.Do(req)
	if err != nil {
		return err
	}
	defer resp.Body.Close()
	return nil
}

otelhttp.NewHandler extracts an incoming traceparent header (if present) and starts a new child span under it; otelhttp.NewTransport does the reverse on the way out, injecting the current span's trace context into the outgoing request's headers. Because both sides use the same propagator, a request entering at the gateway and eventually reaching the inventory service three hops later arrives with the same trace ID intact the whole way — this is the entire mechanism that makes a distributed trace distributed.

Custom spans for the parts that matter

Auto-instrumentation covers HTTP boundaries; the interesting business logic inside a handler usually deserves its own span:

import (
	"context"

	"go.opentelemetry.io/otel"
	"go.opentelemetry.io/otel/attribute"
)

var tracer = otel.Tracer("orders-api")

func processOrder(ctx context.Context, order Order) error {
	ctx, span := tracer.Start(ctx, "processOrder")
	defer span.End()

	span.SetAttributes(attribute.String("order.id", order.ID))

	if err := validateInventory(ctx, order); err != nil {
		span.RecordError(err)
		return err
	}
	return chargePayment(ctx, order)
}

span.RecordError attaches the error to the span itself, which is what lets you filter a trace view down to "show me every trace where a span recorded an error," rather than cross-referencing timestamps against a separate log stream by hand.

Correlating logs, metrics, and traces

The real payoff of tracing isn't the trace view alone — it's linking it to the logs and metrics from the previous chapter so an engineer can move between all three from a single starting point. Two mechanisms make that possible.

Trace-aware logging: pull the current trace and span ID out of context and attach them to every structured log line, so a log line and a trace span referencing the same request can be found by the same ID:

import (
	"context"
	"log/slog"

	"go.opentelemetry.io/otel/trace"
)

func logWithTrace(
	ctx context.Context, logger *slog.Logger, msg string, args ...any,
) {
	span := trace.SpanFromContext(ctx)
	sc := span.SpanContext()
	args = append(args,
		"trace_id", sc.TraceID().String(),
		"span_id", sc.SpanID().String())
	logger.InfoContext(ctx, msg, args...)
}

Exemplars: a Prometheus histogram observation can carry an exemplar — a single sample data point tagged with the trace ID active at the moment it was recorded. Instead of just seeing "p99 latency spiked at 14:03," a dashboard with exemplars lets you click that specific point on the histogram and jump directly to one of the actual traces that produced it:

requestDuration.(prometheus.ExemplarObserver).ObserveWithExemplar(
	time.Since(start).Seconds(),
	prometheus.Labels{
		"trace_id": trace.SpanContextFromContext(ctx).TraceID().String(),
	},
)

Sampling: you don't need every trace

Capturing a full trace for every single request is rarely necessary and can be expensive at high traffic volumes — the value of tracing comes from having enough representative traces to diagnose problems, not from an exhaustive record of every request that ever succeeded quickly. sdktrace.NewTracerProvider accepts a sampler that decides, per trace, whether to actually record it:

tp := sdktrace.NewTracerProvider(
	sdktrace.WithBatcher(exporter),
	sdktrace.WithResource(res),
	sdktrace.WithSampler(sdktrace.ParentBased(sdktrace.TraceIDRatioBased(0.1))),
)

TraceIDRatioBased(0.1) samples roughly ten percent of new traces, and ParentBased ensures that if an upstream service already decided to sample a trace, downstream services honor that same decision rather than each service flipping its own independent coin — otherwise you'd end up with fragments of a trace where some services recorded spans and others didn't, defeating the purpose of a connected trace entirely. A common refinement is sampling all error traces at 100 percent regardless of the base rate, since the traces you need most are exactly the ones representing something that went wrong.

Frequently Asked Questions

Do I need to add a span to every single function to get useful traces? No, and trying to would bury the signal you actually care about. otelhttp.NewHandler and otelhttp.NewTransport already give you a span at every HTTP boundary for free, which is usually enough to see which service ate the time. Reach for a manual tracer.Start call only around business logic you'd otherwise have to guess about, like processOrder in this chapter — a span around every helper function just adds noise to the trace view without adding insight.

What happens if I forget otel.SetTextMapPropagator(propagation.TraceContext{})? Each service still generates spans just fine, but they stop belonging to the same trace. Without a shared propagator, an incoming request gets a fresh trace ID at every hop instead of continuing the one from upstream, so your tracing backend shows a pile of disconnected single-span traces rather than one connected story — which defeats the entire point of distributed tracing.

If I turn on sampling, don't I lose exactly the trace I need later? That's the worry ParentBased(TraceIDRatioBased(0.1)) is built to avoid for the common case: whatever the upstream service decided, downstream services honor it, so a sampled trace stays whole instead of fragmenting. The remaining risk is the rare request that turns into an error after being sampled out — which is why teams commonly sample error traces at 100 percent regardless of the base rate, so the traces you're most likely to need are never the ones you threw away.

Are exemplars just a fancier metric, or a replacement for tracing? Neither — they're a pointer from one signal to the other. The metric still does the cheap job of showing "how much" and "how often" across all traffic; the exemplar just tags one sample with the trace ID that was active when it was recorded, so a spike on a histogram becomes a single click into the one trace that explains it, instead of a separate cross-referencing exercise against timestamps.

How is this chapter's tracing different from the logging and metrics in the previous chapter? Logs and metrics live inside one service and describe what that service did; a trace crosses service boundaries and describes what the whole request did, tying together every hop with a single trace ID. The trace-aware logging and exemplar sections in this chapter exist specifically to stitch the three signals back together, so you can start at any one of them — a log line, a metric spike, or a trace — and jump straight to the others for the same request.

A single service's logs tell you what it did; a trace tells you what the whole request did — and once you can jump between a metric spike, a trace, and the exact log line behind it, "why is this slow" stops being a multi-hour investigation and becomes a click.
