Hexagonal Architecture (Ports and Adapters) for Go APIs

Chapter 6.39 drew Clean Architecture as concentric rings and established the rule that matters: dependencies point inward, and domain logic never imports a framework or a driver. Alistair Cockburn's Hexagonal Architecture — also called Ports and Adapters — arrives at almost the same place from a different picture, and it's worth learning both because you'll meet both vocabularies in the wild, often describing the same codebase.

Cockburn coined the term in the early 2000s specifically to push back against the then-common assumption that a web application's "natural" shape is UI on one side and database on the other, with business logic sandwiched in between and quietly coupled to both. The hexagon is a deliberate visual correction: no side of the shape is more central than any other, and the only privileged position belongs to whatever sits inside it.

Hexagon, Not Rings

Instead of rings, picture a hexagon. Inside it sits the application core — your domain model and use cases, exactly like the inner two rings of Clean Architecture. Each side of the hexagon is a port: an interface the core defines, describing something it needs from, or offers to, the outside world. Outside the hexagon, adapters plug into those ports — one adapter per side, translating between the core's language and some specific technology.

The hexagon shape isn't just decoration; it encodes the pattern's one real addition over how people often picture Clean Architecture. Cockburn draws attention to a symmetry: every adapter is "outside," whether it's a thing that drives the application (an HTTP handler calling into your use case because a request arrived) or a thing the application drives (a Postgres repository the application calls because it needs to persist something). Clean Architecture's rings can read, at a glance, as if HTTP sits somewhere different from the database — outer ring versus outer ring, sure, but a diagram of circles doesn't foreground the "driving vs. driven" distinction the way six equal sides of a hexagon do.

Driving vs. driven, concretely

• A driving adapter (also "primary adapter") initiates action: an HTTP handler, a CLI command, a scheduled job — anything that calls into the application core because something external happened.
• A driven adapter (also "secondary adapter") is called by the application core to satisfy a need it declared as a port: a Postgres repository, an email sender, a payment gateway client.

Both are adapters. Both live outside the hexagon. Both are replaceable without the core noticing, provided they satisfy the port's interface.

Ports for the Order-Management Core

Continuing the order-management example from Chapter 6.39, this section folds the domain and usecase packages into a single core package, purely to keep the hexagon metaphor's vocabulary front and center — the capstone in Chapter 6.42 goes back to the domain/usecase split from Chapter 6.39, since that separation is worth keeping once a project grows past a single example. The application core defines two ports it needs — one for persistence, one to publish what happened after a change:

// internal/core/ports.go
package core

import "context"

type OrderRepository interface {
	FindByID(ctx context.Context, id string) (*Order, error)
	Save(ctx context.Context, o *Order) error
}

type DomainEvent interface {
	EventName() string
}

type EventPublisher interface {
	Publish(ctx context.Context, event DomainEvent) error
}

Order, NewOrder, and ErrOrderNotPaid (used throughout this chapter's code) are the same domain/order.go types from Chapter 6.39, folded here into the core package along with the use case — this chapter reuses that file rather than redefining it. DomainEvent here is a small preview of a concept Chapter 6.41 develops much further; the only requirement it places on an event is that it can name itself.

OrderRepository is a driven port — the core calls out through it. EventPublisher is also driven — publishing an OrderShipped event (the kind of event Chapter 6.23 covers turning into an outbound webhook) is something the core asks for, not something that asks the core for anything. The use case that ships an order depends on both, entirely through interfaces:

// internal/core/ship_order.go
package core

import "context"

type OrderShipped struct {
	OrderID string
}

func (OrderShipped) EventName() string { return "OrderShipped" }

type ShipOrder struct {
	Orders     OrderRepository
	Publisher  EventPublisher
}

func (uc *ShipOrder) Execute(ctx context.Context, orderID string) error {
	order, err := uc.Orders.FindByID(ctx, orderID)
	if err != nil {
		return err
	}
	if err := order.Ship(); err != nil {
		return err
	}
	if err := uc.Orders.Save(ctx, order); err != nil {
		return err
	}
	return uc.Publisher.Publish(ctx, OrderShipped{OrderID: order.ID})
}

A Driving Adapter: the HTTP Handler

// internal/adapter/http/handler.go
package http

import (
	"encoding/json"
	"errors"
	"net/http"

	"ordermgmt/internal/core"
)

type OrderHandler struct {
	ShipOrder *core.ShipOrder
}

func (h *OrderHandler) Ship(w http.ResponseWriter, r *http.Request) {
	orderID := r.PathValue("id")

	err := h.ShipOrder.Execute(r.Context(), orderID)
	switch {
	case err == nil:
		w.WriteHeader(http.StatusOK)
	case errors.Is(err, core.ErrOrderNotPaid):
		w.WriteHeader(http.StatusConflict)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
	default:
		w.WriteHeader(http.StatusInternalServerError)
	}
}

This handler is a thin translator: it pulls an ID out of the URL (routing patterns like this are covered in Chapter 6.4), calls the port, and maps domain errors onto HTTP status codes. It contains zero business logic — notice it doesn't know what "shipped" means, only that ErrOrderNotPaid maps to 409 Conflict.

A second driving adapter, for free

The symmetry Hexagonal Architecture emphasizes shows up clearly the moment a second driving adapter appears. Suppose an internal operations tool needs a one-off CLI command to ship an order manually:

// cmd/opstool/ship.go
package main

import (
	"context"
	"fmt"
	"os"

	"ordermgmt/internal/core"
)

func shipCommand(uc *core.ShipOrder, orderID string) {
	if err := uc.Execute(context.Background(), orderID); err != nil {
		fmt.Fprintln(os.Stderr, "ship failed:", err)
		os.Exit(1)
	}
	fmt.Println("order shipped")
}

Nothing about core.ShipOrder changed to support this. The CLI command and the HTTP handler are both driving adapters calling the identical port; one translates a URL path segment into an order ID, the other translates an os.Args entry into the same string. Neither adapter can shortcut the ErrOrderNotPaid check — it isn't theirs to shortcut, since it lives one layer further in, on the port's other side.

A Driven Adapter: Postgres

// internal/adapter/postgres/order_repository.go
package postgres

import (
	"context"

	"github.com/jackc/pgx/v5/pgxpool"

	"ordermgmt/internal/core"
)

type OrderRepository struct {
	pool *pgxpool.Pool
}

func NewOrderRepository(pool *pgxpool.Pool) *OrderRepository {
	return &OrderRepository{pool: pool}
}

func (r *OrderRepository) FindByID(
	ctx context.Context, id string,
) (*core.Order, error) {
	var o core.Order
	row := r.pool.QueryRow(ctx,
		`SELECT id, customer_id, status FROM orders WHERE id = $1`, id)
	if err := row.Scan(&o.ID, &o.CustomerID, &o.Status); err != nil {
		return nil, err
	}
	return &o, nil
}

func (r *OrderRepository) Save(ctx context.Context, o *core.Order) error {
	_, err := r.pool.Exec(ctx,
		`UPDATE orders SET status = $2 WHERE id = $1`, o.ID, o.Status)
	return err
}

This satisfies core.OrderRepository implicitly, exactly as in Chapter 6.39. Hexagonal Architecture doesn't add anything new mechanically here — it just gives this file a name ("a driven adapter for the persistence port") that foregrounds its symmetry with the HTTP handler above ("a driving adapter for the same core").

The Payoff: an In-Memory Adapter for Testing

The reason this pattern earns its keep day to day is testability. Because ShipOrder depends only on the OrderRepository and EventPublisher interfaces, a second driven adapter — one with no database at all — can stand in during tests:

// internal/adapter/memory/order_repository.go
package memory

import (
	"context"
	"errors"
	"sync"

	"ordermgmt/internal/core"
)

type OrderRepository struct {
	mu     sync.Mutex
	orders map[string]*core.Order
}

func NewOrderRepository() *OrderRepository {
	return &OrderRepository{orders: make(map[string]*core.Order)}
}

func (r *OrderRepository) Put(o *core.Order) {
	r.mu.Lock()
	defer r.mu.Unlock()
	r.orders[o.ID] = o
}

func (r *OrderRepository) FindByID(
	ctx context.Context, id string,
) (*core.Order, error) {
	r.mu.Lock()
	defer r.mu.Unlock()
	o, ok := r.orders[id]
	if !ok {
		return nil, errors.New("order not found")
	}
	return o, nil
}

func (r *OrderRepository) Save(ctx context.Context, o *core.Order) error {
	r.mu.Lock()
	defer r.mu.Unlock()
	r.orders[o.ID] = o
	return nil
}

And a matching fake for the publisher port, kept in the test file itself since it only needs to record what it saw:

// internal/core/ship_order_test.go
package core_test

import (
	"context"
	"testing"

	"ordermgmt/internal/adapter/memory"
	"ordermgmt/internal/core"
)

type recordingPublisher struct {
	events []string
}

func (p *recordingPublisher) Publish(
	ctx context.Context, event core.DomainEvent,
) error {
	p.events = append(p.events, event.EventName())
	return nil
}

func TestShipOrder_RejectsUnpaidOrder(t *testing.T) {
	repo := memory.NewOrderRepository()
	order := core.NewOrder("order-1", "cust-1")
	repo.Put(order)

	pub := &recordingPublisher{}
	uc := &core.ShipOrder{Orders: repo, Publisher: pub}

	err := uc.Execute(context.Background(), "order-1")

	if err != core.ErrOrderNotPaid {
		t.Fatalf("want ErrOrderNotPaid, got %v", err)
	}
	if len(pub.events) != 0 {
		t.Fatalf("expected no events published, got %v", pub.events)
	}
}

func TestShipOrder_PublishesEventOnSuccess(t *testing.T) {
	repo := memory.NewOrderRepository()
	order := core.NewOrder("order-1", "cust-1")
	order.MarkPaid()
	repo.Put(order)

	pub := &recordingPublisher{}
	uc := &core.ShipOrder{Orders: repo, Publisher: pub}

	if err := uc.Execute(context.Background(), "order-1"); err != nil {
		t.Fatalf("unexpected error: %v", err)
	}
	if len(pub.events) != 1 || pub.events[0] != "OrderShipped" {
		t.Fatalf("expected OrderShipped event, got %v", pub.events)
	}
}

This test suite runs in milliseconds, needs no database connection, no Docker container, no network — and it's testing the exact same business rule (ErrOrderNotPaid) that will run in production against real Postgres. That's the concrete payoff of ports and adapters: business logic correctness and infrastructure correctness become two separate concerns, tested separately, at different speeds.

Clean Architecture and Hexagonal, Side by Side

In both, the practical Go mechanism is identical: define the interface next to the code that needs it, implement it in a separate package that the interface's owner never imports. The names differ; the compiler-enforced discipline does not.

Adopting this incrementally in an existing codebase doesn't require a rewrite. Start with the highest-value seam first — usually the repository, since a database is the slowest and hardest-to-set-up dependency in most test suites. Extract an interface for whatever your handlers currently call directly, write an in-memory implementation, and let your existing tests start using it. Only once that's paying off does it make sense to widen the boundary further — a driving-adapter split for a CLI, a second driven adapter for an email or payment provider — one port at a time, in the order that removes the most pain first.

A port is just an interface with a name that tells you which direction the call goes — naming it well is documentation, not architecture.

Frequently Asked Questions

Is a "port" in this chapter a different thing from a network port (like TCP port 8080)? Completely different, and the name collision trips people up the first time they meet it. A port here is just an interface owned by the application core — OrderRepository and EventPublisher are both ports — describing a capability the core needs or offers. It has nothing to do with a numeric address on a socket; Cockburn simply reused an everyday English word ("a place where things connect") for an unrelated idea.

Why does EventPublisher count as a driven port when the core is the one calling Publish? Because "driving" and "driven" describe who initiates the call, not who does more work. The core calls out through EventPublisher to ask for something to happen — publish this event — exactly the same direction as calling out to OrderRepository to save a row. A driving adapter, by contrast, is whatever calls into the core uninvited, like an HTTP request arriving. Both OrderRepository and EventPublisher sit on the "driven" side because the core is always the one reaching outward through them.

Why bother giving the CLI command in cmd/opstool/ship.go its own adapter instead of just calling core.ShipOrder directly from main? It already is calling it directly — that's the point being illustrated, not a gap. The CLI function and the HTTP handler are both thin driving adapters wrapping the identical port, and neither one needed core.ShipOrder to change at all to support it. That symmetry — two completely different entry points sharing one unmodified core — is exactly what the hexagon's six equal sides are trying to make visible that a stack of rings tends to hide.

The in-memory OrderRepository in the testing section looks good enough to use as a cache — why does the chapter warn against that? Because a test double is optimized for one job: being simple and predictable inside a test run. A real cache needs invalidation rules, consistency guarantees under concurrent writers, and an eviction policy, none of which the fake was ever designed to get right. The warning above is there because this exact promotion — "it already satisfies the interface, why not use it in production" — is a common way test-only code quietly becomes load-bearing infrastructure.

Do I need to migrate an existing codebase to ports and adapters all at once? No, and the chapter argues against it — start with whichever dependency is slowest to set up in tests, which for most services is the database. Extract an interface for what your handlers currently call directly, write an in-memory implementation, and let existing tests use it before widening the boundary any further. One port at a time, in the order that removes the most pain first, is the whole migration strategy.

Key Takeaways

• Hexagonal Architecture's ports are the same interfaces Clean Architecture calls repository/gateway interfaces — the vocabulary differs, the compiler-level rule (core never imports an adapter) is identical.
• The driving/driven distinction is the pattern's one genuinely useful addition: it names the difference between adapters that call into your core (HTTP handlers) and adapters your core calls out to (databases, publishers).
• The concrete payoff is testability: swap a driven adapter for an in-memory fake and test business rules with no database, no network, and millisecond-fast tests.
• Don't repurpose a test-only adapter as production infrastructure just because it happens to satisfy the same interface.
• Pick Clean or Hexagonal vocabulary based on what your team already knows — the code they produce converges regardless.
