SIEM and Log Analysis for Network Security

A single firewall log tells you one connection was blocked. A single server log tells you one login succeeded. Neither tells you a breach happened. Put both in the same room, correlate them by time and identity, and the story suddenly writes itself. That correlation room is what a SIEM is for.

What a SIEM Actually Does

SIEM stands for Security Information and Event Management, and the name describes two jobs that used to be separate products. Security Information Management is the collection, normalization, and long-term storage of log data. Security Event Management is the real-time correlation and alerting layer on top of it. Modern platforms (Splunk, Elastic Security, Microsoft Sentinel, and open-source stacks built on the Elastic stack or Wazuh) merge both into a single pipeline:

  1. Collection - agents, syslog forwarders, and API integrations pull logs from firewalls, routers, IDS/IPS sensors, DNS resolvers, authentication systems, endpoints, and cloud audit trails.
  2. Normalization - wildly different log formats get parsed into a common schema (timestamp, source, destination, user, action, outcome) so a query can span every source at once.
  3. Correlation - rules or models tie discrete events together across sources and time, turning "failed login" plus "unusual outbound connection" plus "new scheduled task" into a single flagged incident instead of three ignorable noise items.
  4. Alerting and response - matches trigger notifications, tickets, or automated playbooks (which overlaps heavily with the automation techniques covered later in this part).
  5. Retention and search - logs are kept for a compliance-driven window (often 90 days to a year or more) so analysts can retroactively hunt once a new indicator of compromise becomes known.

Why Correlation Beats Single-Source Alerting

Any individual security tool only sees its own slice of the environment. A firewall sees connections; it doesn't know which user account initiated them. An identity provider sees logins; it doesn't know what that session did on the network afterward. A SIEM's entire value proposition is stitching these fragments into a timeline for one entity - a user, a host, an IP - across every system that touched it.

This is also why log normalization matters so much in practice. If your firewall logs timestamps in UTC and your Windows event logs are in local time, or one source calls the field src_ip and another calls it source_address, correlation silently breaks. Most of the unglamorous engineering effort in running a SIEM goes into keeping every source mapped into the same schema.

Correlation Rules and Use Cases

A useful way to think about SIEM rules is as codified analyst intuition. A few classic examples:

  • Impossible travel: the same user account authenticates from two geographically distant locations within a time window too short for actual travel.
  • Brute-force followed by success: many failed logins from one source, followed by a success, especially against a privileged account.
  • Beaconing: a host makes outbound connections to the same external address at suspiciously regular intervals - a strong indicator of malware phoning home (covered in more depth in the malware chapter).
  • Data staging: a host that normally never touches large file shares suddenly reads a large volume of data shortly before an unusual outbound transfer.

None of these individually proves compromise; each is a hypothesis worth investigating. Tuning a SIEM is largely the ongoing work of adjusting thresholds so these rules catch real incidents without burying analysts in false positives - the same alert-fatigue problem introduced in the IDS/IPS chapter, just at a larger scale spanning the whole environment.

A Minimal Normalization Pipeline in Go

Most of what a SIEM's ingestion layer does, at its core, is take heterogeneous text and turn it into structured, comparable events. A small Go program illustrates the idea: parse loosely-formatted log lines and normalize them into a common JSON event shape.

package main

import (
	"bufio"
	"encoding/json"
	"fmt"
	"regexp"
	"strings"
	"time"
)

// NormalizedEvent is the common schema every log source gets mapped into,
// regardless of its original format.
type NormalizedEvent struct {
	Timestamp time.Time `json:"timestamp"`
	Source    string    `json:"source"`
	SourceIP  string    `json:"source_ip"`
	Action    string    `json:"action"`
	Outcome   string    `json:"outcome"`
}

var firewallLine = regexp.MustCompile(`^(\S+ \S+) BLOCK src=(\S+)`)

func normalizeFirewallLog(line string) (NormalizedEvent, bool) {
	m := firewallLine.FindStringSubmatch(line)
	if m == nil {
		return NormalizedEvent{}, false
	}
	ts, err := time.Parse("2006-01-02 15:04:05", m[1])
	if err != nil {
		return NormalizedEvent{}, false
	}
	return NormalizedEvent{
		Timestamp: ts,
		Source:    "firewall",
		SourceIP:  m[2],
		Action:    "connection_blocked",
		Outcome:   "denied",
	}, true
}

func main() {
	raw := strings.NewReader(
		`2024-03-01 08:15:03 BLOCK src=203.0.113.55 dst=10.0.0.4:22
not a log line we understand
2024-03-01 08:15:07 BLOCK src=203.0.113.55 dst=10.0.0.5:22
`)

	scanner := bufio.NewScanner(raw)
	for scanner.Scan() {
		if event, ok := normalizeFirewallLog(scanner.Text()); ok {
			payload, _ := json.Marshal(event)
			fmt.Println(string(payload))
		}
	}
}

Each vendor's real log format is messier than this example, but the shape of the problem never changes: parse, extract the fields that matter, discard or quarantine what fails to parse, and emit a consistent structure downstream. Once every source speaks the same JSON schema, writing a correlation rule - "same source_ip blocked more than three times in sixty seconds" - becomes a straightforward query instead of a cross-format nightmare.

Frequently Asked Questions

We already have a firewall and an IDS with their own alerts. Why do we still need a SIEM on top of them? Because each of those tools only narrates its own slice of the story. The firewall can tell you a connection was blocked, and the identity provider can tell you a login happened, but neither one knows about the other's event, let alone that they belong to the same incident. A SIEM's entire reason for existing is stitching those separate fragments into one timeline for a given user, host, or address.

Our correlation rules keep firing on things that turn out to be harmless. Is the SIEM broken? No, that's the normal cost of the approach, not a malfunction. Every rule in this chapter - impossible travel, brute-force-then-success, beaconing, data staging - is a hypothesis, not a proof of compromise, and tuning thresholds against real traffic to cut false positives without missing real incidents is ongoing work, the same alert-fatigue problem the IDS/IPS chapter raised, just spread across the whole environment instead of one sensor.

If we can only onboard a few log sources at first, does it matter which ones we pick? It matters enormously. Authentication logs, DNS query logs, firewall/flow logs, and endpoint process logs give the highest signal for the least onboarding effort, because network visibility without identity context and identity logs without network context each leave a blind spot the other one fills. Starting with those four covers far more realistic attack paths than onboarding ten obscure sources nobody correlates against anything.

Why does the Go example bother normalizing log lines into JSON instead of just searching the raw text? Because correlation only works once every source speaks the same schema. If the firewall logs timestamps in UTC and another source uses local time, or one calls a field src_ip and another calls it source_address, a query trying to span both breaks silently. The normalization step - regex-parse, extract the fields that matter, discard what fails - is what turns "same source_ip blocked three times in sixty seconds" from a cross-format nightmare into a simple query.

How does beaconing detection here connect to the malware chapter that follows? A SIEM notices beaconing as a pattern - the same external address contacted at suspiciously regular intervals - without necessarily knowing what's causing it. The malware analysis chapter picks up exactly where that pattern leaves off, digging into what a piece of malware's command-and-control traffic actually looks like on the wire, so the indicator a SIEM flags becomes something you can positively identify rather than just suspect.

Summary

  • A SIEM's value comes from correlation across sources, not from any single log in isolation.
  • Normalization is the unglamorous but essential step that makes correlation possible at all.
  • Prioritize identity, DNS, network flow, and endpoint logs first - they cover the most common attack patterns with the least onboarding effort.
  • Tuning correlation rules against real traffic is an ongoing process, not a one-time setup task.
