Custom Protocol Design and Implementation

"Two people inventing a board game together need to agree on more than the pieces. Whose turn goes first? How do you signal that your turn is over? What happens if someone disconnects mid-game? What counts as a valid move, and what happens when an invalid one arrives? A protocol is exactly that set of agreed rules, written down precisely enough that two independently written programs, possibly years apart, can still play the same game correctly."

Every protocol you have used in this book -- HTTP, WebSocket, gRPC's framing over HTTP/2 -- is somebody else's answer to this design problem. Sometimes their answer does not fit yours: you need less overhead than HTTP for a high-frequency binary stream, or semantics that neither HTTP nor a generic message queue quite captures. net.Conn gives you a raw, ordered byte stream (over TCP) or discrete datagrams (over UDP); everything above that -- what a "message" is, how you know where one ends and the next begins, how you version the format -- is your job to define. This chapter is about doing that job well.

The Core Problem: Framing

TCP gives you a stream of bytes with no message boundaries at all -- a single Write on one end can arrive as multiple Reads on the other, or multiple Writes can coalesce into one Read. If your protocol has any concept of a discrete "message," you must invent a way to mark where each one starts and ends. There are three common strategies:

• Delimiter-based: end each message with a sentinel byte sequence (like \r\n in HTTP/1.1 headers). Simple, but the delimiter can never appear in the payload unless you escape it, which adds its own complexity.
• Length-prefixed: send a fixed-size header containing the length of the message that follows, then exactly that many bytes. No escaping needed, and the reader knows in advance exactly how much to read. This is the approach most binary protocols -- including HTTP/2 and gRPC's framing -- actually use.
• Fixed-size messages: every message is the same number of bytes. Simplest of all, but wasteful or outright unworkable for variable-length payloads.

Length-prefixing is the right default for most custom binary protocols, and it is what the implementation below uses.

Designing the Header

Beyond framing, a serious protocol header usually carries a version (so you can evolve the format without breaking old clients), a type or opcode (so a single connection can carry different kinds of messages), and the length itself. Everything after the header is the payload, whose interpretation depends on the type field.

package protocol

import (
	"encoding/binary"
	"errors"
	"io"
)

const (
	Version1 uint8 = 1

	TypePing    uint8 = 0
	TypePong    uint8 = 1
	TypeMessage uint8 = 2
)

// Header is fixed-size and always sent first: 1 byte version,
// 1 byte type, 4 bytes big-endian length of the payload that follows.
type Header struct {
	Version uint8
	Type    uint8
	Length  uint32
}

const headerSize = 6

func (h Header) Encode() []byte {
	buf := make([]byte, headerSize)
	buf[0] = h.Version
	buf[1] = h.Type
	binary.BigEndian.PutUint32(buf[2:], h.Length)
	return buf
}

func DecodeHeader(buf []byte) (Header, error) {
	if len(buf) < headerSize {
		return Header{}, errors.New("buffer too small for header")
	}
	return Header{
		Version: buf[0],
		Type:    buf[1],
		Length:  binary.BigEndian.Uint32(buf[2:]),
	}, nil
}

Big-endian ("network byte order") is the conventional choice for wire formats -- it is what most established protocols use, and picking it explicitly (rather than relying on host byte order) is what makes your protocol work identically whether the two ends are little-endian x86 machines or big-endian hardware.

Reading a Message Safely

The critical correctness point when reading length-prefixed data: a single conn.Read call is not guaranteed to fill your buffer, even if the sender wrote it all at once. You must loop until you have exactly the bytes you asked for, which is precisely what io.ReadFull does:

package protocol

import (
	"fmt"
	"io"
)

type Message struct {
	Header  Header
	Payload []byte
}

func ReadMessage(r io.Reader) (*Message, error) {
	headerBuf := make([]byte, headerSize)
	if _, err := io.ReadFull(r, headerBuf); err != nil {
		return nil, fmt.Errorf("reading header: %w", err)
	}

	header, err := DecodeHeader(headerBuf)
	if err != nil {
		return nil, err
	}

	// Refuse to allocate unbounded memory for a hostile length.
	const maxPayload = 16 * 1024 * 1024
	if header.Length > maxPayload {
		return nil, fmt.Errorf("payload too large: %d bytes", header.Length)
	}

	payload := make([]byte, header.Length)
	if _, err := io.ReadFull(r, payload); err != nil {
		return nil, fmt.Errorf("reading payload: %w", err)
	}

	return &Message{Header: header, Payload: payload}, nil
}

func WriteMessage(w io.Writer, msgType uint8, payload []byte) error {
	header := Header{
		Version: Version1,
		Type:    msgType,
		Length:  uint32(len(payload)),
	}
	if _, err := w.Write(header.Encode()); err != nil {
		return fmt.Errorf("writing header: %w", err)
	}
	if _, err := w.Write(payload); err != nil {
		return fmt.Errorf("writing payload: %w", err)
	}
	return nil
}

The maxPayload guard is not optional polish -- without it, a malicious or buggy peer can send a Header.Length of close to 4 GiB and force your server to allocate that much memory before it even sees whether the rest of the data ever arrives. Any protocol that trusts a length field from the network needs an upper bound.

Putting It Together: A Minimal Server and Client

func handleConn(conn net.Conn) {
	defer conn.Close()
	for {
		msg, err := protocol.ReadMessage(conn)
		if err != nil {
			return // connection closed or malformed stream
		}
		switch msg.Header.Type {
		case protocol.TypePing:
			protocol.WriteMessage(conn, protocol.TypePong, nil)
		case protocol.TypeMessage:
			log.Printf("received: %s", msg.Payload)
		}
	}
}

Because every message is self-delimiting, this loop works whether the peer sends one message per TCP segment or batches ten of them into a single Write -- ReadMessage will keep pulling exactly as many bytes as each header promises, for as long as the connection stays open.

Versioning and Evolution

Put the version byte in from day one, even if you only ever ship Version1 for the first year. When you need to add a field, you have two honest options: bump the version and require both ends to negotiate a shared version during connection setup, or design the payload format itself to be forward-compatible (a length-prefixed list of optional fields, similar in spirit to protobuf's tag-based approach from the gRPC chapter). Retrofitting either strategy after a protocol has shipped without a version field is far more painful than reserving the byte up front.

A protocol is not the bytes you send -- it is the promises both sides agree to keep about what those bytes mean.

Frequently Asked Questions

Why not just use delimiters like HTTP/1.1 does, instead of a length-prefixed header? Delimiters work fine when your payload is text you control, like HTTP headers, but they fall apart the moment the payload is arbitrary binary data that might legitimately contain your delimiter bytes. Length-prefixing sidesteps the whole escaping problem: the reader is told exactly how many bytes to expect and never has to scan the payload looking for a terminator, which is why HTTP/2 and gRPC's own framing both moved to it.

I called conn.Read once with a big buffer -- why did I only get part of my message? Because TCP makes no promise that a single Read fills your buffer, even if the sender wrote everything in one Write -- the two ends do not share a notion of "message," only a stream of bytes that can be sliced up differently by the network. That is exactly why ReadMessage in this chapter uses io.ReadFull rather than a bare Read: it loops internally until it has the exact number of bytes the header promised, or it gives up with an error.

What actually stops a malicious peer from crashing my server with a huge length field? The maxPayload guard in ReadMessage is what stops it. Without an upper bound, a hostile or buggy sender could put a Header.Length near 4 GiB into a 4-byte field and force your server to allocate that much memory before ever verifying the rest of the data shows up -- any time you trust a length value read off the network, it needs a ceiling checked before you allocate.

Do I really need a version byte if I only have one version of my protocol today? Yes, put it in from the start. The whole point is that reserving the byte costs you nothing on day one, while adding it later means every already-deployed peer suddenly needs to be taught to expect a byte that used to not exist -- a breaking change you could have avoided entirely by planning for evolution before you needed it.

How does this connect to the state machine idea in the DeepDive above? Framing (this chapter's main subject) tells you where one message ends and the next begins; a state machine tells you whether a message that arrived in the right shape is even allowed to arrive now. Both are part of the same discipline -- a protocol is not just a byte layout, it is a set of promises about order and meaning, which is the idea the closing Axiom is pointing at.

Key Takeaways

• net.Conn gives you an ordered byte stream or discrete datagrams; defining what a "message" is, and where one ends, is your own protocol's job.
• Length-prefixed framing is the right default for most binary protocols -- no escaping needed, and the reader knows exactly how much to read.
• io.ReadFull is required for reading length-prefixed data correctly, because a single conn.Read is never guaranteed to fill your buffer.
• A length field read off the network needs an upper bound before you allocate, or a hostile peer can force unbounded memory use.
• Put a version byte in from day one; retrofitting one after a protocol has shipped is far more painful than reserving it up front.
