Orchestration, Replicas, and Graceful Shutdown

Chapter 6.17 introduced running multiple replicas behind a load balancer and sketched a first graceful shutdown using signal.NotifyContext and http.Server.Shutdown. This chapter goes deeper on both halves of that picture: exactly what running replicas demands from how you write the API, and the precise, complete shutdown sequence a production Go service needs to survive rolling deploys, node drains, and autoscaling events without dropping a single in-flight request.

Why Replicas, and What They Demand

A single Go process can hold open thousands of concurrent connections, so replicas aren't primarily about raw throughput — they're about failure isolation. One replica crashing, one node rebooting, one instance being replaced mid-deploy should never be visible to a client as downtime, and that's only true if a load balancer can send the next request to any replica and get an identical answer.

That constraint reaches back into how the API is written, not just how it's deployed: no handler may assume a previous request from the same client landed on the same process. Concretely, that means no in-memory session map, no local-disk cache of uploaded files, no "the counter is at 42 in this process's memory" logic — any state that needs to survive between requests belongs in a shared store (Redis, Postgres, object storage) that every replica reaches identically. Chapter 6.17 covers this statelessness requirement in more detail; the rest of this chapter assumes it and focuses on the orchestration mechanics built on top of it.

A session lookup makes the difference concrete. The version below only works as long as every request from the same client happens to land on the same replica — true on a developer's laptop with one process, false the moment there are three replicas and a load balancer:

// Fragile: state lives only in this one process's memory.
var sessions = map[string]Session{}

func currentSession(r *http.Request) (Session, bool) {
	cookie, err := r.Cookie("session_id")
	if err != nil {
		return Session{}, false
	}
	s, ok := sessions[cookie.Value]
	return s, ok
}

A replica that never saw the request that created a given session simply doesn't have it — the user gets logged out at random, depending on which replica the load balancer happens to pick next. Moving the lookup to a shared store fixes it for any number of replicas, present or future:

// Correct: any replica can serve any request identically.
func currentSession(ctx context.Context, r *http.Request,
	rdb *redis.Client) (Session, bool) {

	cookie, err := r.Cookie("session_id")
	if err != nil {
		return Session{}, false
	}
	data, err := rdb.Get(ctx, "session:"+cookie.Value).Bytes()
	if err != nil {
		return Session{}, false
	}
	var s Session
	if json.Unmarshal(data, &s) != nil {
		return Session{}, false
	}
	return s, true
}

A Real Deployment, Probes, and a Disruption Budget

apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapi
spec:
  replicas: 3
  selector:
    matchLabels: {app: myapi}
  template:
    metadata:
      labels: {app: myapi}
    spec:
      terminationGracePeriodSeconds: 30
      containers:
        - name: myapi
          image: registry.example.com/myapi:1.5.0
          ports:
            - containerPort: 8080
          readinessProbe:
            httpGet: {path: /readyz, port: 8080}
            periodSeconds: 5
            failureThreshold: 1
          livenessProbe:
            httpGet: {path: /healthz, port: 8080}
            initialDelaySeconds: 5
            periodSeconds: 10
            failureThreshold: 3

The two probes ask genuinely different questions, and mixing them up is one of the more common Kubernetes mistakes:

A liveness check that also verifies the database connection is a classic bug: if the database has a brief outage, every replica's liveness probe fails at once, Kubernetes restarts all of them simultaneously, and a database hiccup turns into a full outage of the API itself. Liveness should answer only "is this process fundamentally stuck," which is why /healthz below does nothing but respond:

func healthzHandler(w http.ResponseWriter, r *http.Request) {
	w.WriteHeader(http.StatusOK)
	w.Write([]byte("ok"))
}

/readyz, by contrast, is exactly where dependency checks and the shutdown-draining logic below belong:

var ready atomic.Bool

func readyzHandler(w http.ResponseWriter, r *http.Request) {
	if !ready.Load() {
		http.Error(w, "not ready", http.StatusServiceUnavailable)
		return
	}
	w.WriteHeader(http.StatusOK)
	w.Write([]byte("ready"))
}

Alongside the two probes, a PodDisruptionBudget protects the replica count during voluntary disruptions — a node drain during a cluster upgrade, or the cluster autoscaler consolidating nodes — as opposed to a pod simply crashing, which no PDB can prevent:

apiVersion: policy/v1
kind: PodDisruptionBudget
metadata:
  name: myapi-pdb
spec:
  minAvailable: 2
  selector:
    matchLabels: {app: myapi}

With minAvailable: 2 set against 3 replicas, Kubernetes will refuse to voluntarily evict a pod if doing so would drop the available count below two — a node drain simply waits, evicting one pod at a time as replacements become ready, instead of taking down two-thirds of the API's capacity at once.

Graceful Shutdown, Precisely

When Kubernetes terminates a pod — during a rollout, a scale-down, or a node drain — it sends SIGTERM and starts a clock: terminationGracePeriodSeconds later, if the process hasn't exited on its own, it receives SIGKILL, which cannot be caught or cleaned up after. Everything in this section exists to make sure the process finishes on its own, well inside that window.

package main

import (
	"context"
	"errors"
	"log"
	"net/http"
	"os/signal"
	"sync/atomic"
	"syscall"
	"time"
)

func main() {
	mux := http.NewServeMux()
	mux.HandleFunc("/healthz", healthzHandler)
	mux.HandleFunc("/readyz", readyzHandler)
	mux.Handle("/", apiHandler())

	srv := &http.Server{Addr: ":8080", Handler: mux}

	ctx, stop := signal.NotifyContext(
		context.Background(), syscall.SIGTERM, syscall.SIGINT,
	)
	defer stop()

	ready.Store(true)
	go func() {
		if err := srv.ListenAndServe(); err != nil &&
			!errors.Is(err, http.ErrServerClosed) {
			log.Fatalf("listen: %v", err)
		}
	}()

	<-ctx.Done()
	log.Println("shutdown signal received, failing readiness")

	// Fail readiness immediately. The Service's endpoint list
	// updates asynchronously across the cluster, so a short
	// pause here bridges the gap before new traffic stops
	// arriving, without yet refusing requests already in flight.
	ready.Store(false)
	time.Sleep(5 * time.Second)

	shutdownCtx, cancel := context.WithTimeout(
		context.Background(), 20*time.Second,
	)
	defer cancel()

	log.Println("draining in-flight requests")
	if err := srv.Shutdown(shutdownCtx); err != nil {
		log.Printf("forced shutdown after deadline: %v", err)
	} else {
		log.Println("shutdown complete")
	}
}

Reading this top to bottom: signal.NotifyContext turns SIGTERM (and, for local testing, Ctrl+C as SIGINT) into a cancelable context.Context instead of the process dying immediately — ctx.Done() closes the instant either signal arrives. The server runs in a goroutine so main is free to block on that context. The moment a signal arrives, ready.Store(false) makes /readyz start failing, so the next readiness probe tells Kubernetes to stop routing new requests to this pod — but the process does not stop serving yet, since requests already routed here need to complete. The five-second sleep exists specifically to cover the propagation delay between the readiness probe failing and every kube-proxy and load balancer in the cluster actually removing this pod's endpoint. Only after that does srv.Shutdown(shutdownCtx) run: it stops accepting new connections and blocks until every in-flight request finishes or the 20-second deadline expires, whichever comes first — a request still running past the deadline is cut off, but everything that finished in time got a real response instead of a dropped connection.

Add up the worst case: 5 seconds of pre-drain sleep plus 20 seconds of shutdown deadline is 25 seconds, which is why the Deployment above sets terminationGracePeriodSeconds: 30 — comfortably longer than the shutdown logic can possibly take, with a small margin left over.

Replicas make an API available; graceful shutdown makes replacing one of them invisible. A fleet of stateless, horizontally scaled instances is only as reliable as the shutdown sequence each individual instance runs when its turn comes to be replaced.

Real-World Example: A Node Drain During a Cluster Upgrade

A cluster administrator runs kubectl drain node-7 to take a node out of service for a Kubernetes version upgrade. node-7 happens to be running one of myapi's three pods. The drain command asks Kubernetes to evict that pod; the PodDisruptionBudget with minAvailable: 2 allows the eviction, since the other two replicas on different nodes stay up throughout. Eviction triggers exactly the same sequence a rolling deploy would: the pod's SIGTERM handler fires, /readyz starts failing immediately, the Service stops routing new traffic to it over the next few seconds, and srv.Shutdown drains whatever was already in flight — all comfortably inside the 30-second grace period. The scheduler places a replacement pod on a healthy node, its readiness probe passes once it's actually able to serve, and traffic resumes flowing to it. From outside the cluster, a client making requests throughout the entire drain sees nothing except perhaps a few milliseconds of added latency on the requests that happened to be mid-flight on node-7 at the moment the drain began — no errors, no dropped connections, because every piece of the mechanism above did exactly the job it was built for.

Frequently Asked Questions

Why does checking the database in a liveness probe feel like the responsible thing to do, and why is it actually the opposite? It feels responsible because a broken database connection genuinely does mean the API can't do its job — surely the orchestrator should know that? But liveness answers a narrower question than that: is this specific process fundamentally stuck, deadlocked, or otherwise beyond recovery by anything short of a restart. A database outage is recoverable the moment the database comes back, and restarting the process does nothing to fix it — it just adds a pointless restart storm on top of an outage that was never the process's fault. That check belongs on /readyz instead, where "not ready right now" is exactly the right, non-destructive answer.

What actually breaks if I skip the five-second sleep between failing readiness and calling srv.Shutdown? Nothing breaks in a demo, which is precisely what makes this one easy to ship broken — it only shows up under real cluster load. The readiness probe failing and every load balancer and kube-proxy in the cluster actually removing this pod's endpoint are two different events separated by a propagation delay that the process itself has no visibility into. Without the sleep, Shutdown can start closing the listener while traffic is still arriving, and those late-arriving requests get connection errors instead of the graceful drain the whole sequence was built to provide.

Does any of this apply if I'm not deploying to Kubernetes? The mechanics of SIGTERM, signal.NotifyContext, and http.Server.Shutdown are just as relevant under systemd, Docker Compose, or a plain docker stop — every one of those sends a termination signal and then a kill signal after some grace period, which is the exact shape this chapter's shutdown sequence is built around. What's specific to Kubernetes is the readiness-probe dance and the PodDisruptionBudget; without an orchestrator routing traffic based on a readiness endpoint, the process can usually skip straight to draining once it decides to stop accepting new connections.

What happens to a request that's still running when the 20-second shutdown deadline expires? srv.Shutdown gives up waiting and returns an error, and any handler still executing past that point gets its connection cut regardless of how far along it was — there's no partial credit for almost finishing. That's a deliberate tradeoff, not an oversight: a bounded deadline is what keeps a single slow request from holding up the entire rollout indefinitely. The right response is sizing the deadline generously above the true worst-case handler duration, and treating a request that regularly needs longer than that as a design problem — background jobs and polling, not a synchronous handler, are usually the actual fix.

Key Takeaways

• Multiple replicas buy availability and horizontal scale, but only if every replica is interchangeable — no per-process state a client's next request might depend on.
• Liveness answers "restart me if this fails"; readiness answers "don't send me traffic yet." Never let a liveness probe depend on an external service.
• A PodDisruptionBudget protects replica count during voluntary disruptions like node drains and cluster upgrades, not against pods simply crashing.
• signal.NotifyContext on SIGTERM, flipping readiness false, a short propagation-bridging sleep, then http.Server.Shutdown(ctx) with a bounded deadline is the complete, correct shutdown sequence.
• Set terminationGracePeriodSeconds comfortably above the worst-case total of that sequence — never equal to it, and never left at a framework default without checking.
